Nozzles

Cutting Nozzles

ANM SHORT PATTERN

6 heating holes, 76 mm long.
Use: Acetylene fuel gas.

Art. Nr.	Range	Size
768554	3 – 6 mm	size 1/32”
768555	5 – 12 mm	size 3/64”
768556	10 – 75 mm	size 1/16”
768557	70 – 100 mm	size 5/64”
768558	90 – 150 mm	size 3/32”
768559	190 – 300 mm	size 1/8”

PNM SHORT PATTERN

9 spline inner, 76 mm long.
Fuel gas : Propane

Art. Nr.	Range	Size	Quantity
768880	3 – 6 mm	size 1/32”	1
768865	5 – 12 mm	size 3/64”	1
768879	10 – 75 mm	size 1/16”	1
768878	70 – 100 mm	size 5/64”	1
769481	90 – 150 mm	size 3/32”	1
769482	190 – 300 mm	size 1/8”	1

ANME LONG PATTERN

6 heating holes, 88 mm long.
Fuel gas: Acetylene

Art. Nr.	Range	Size	Quantity
768670	3 – 6 mm	size 1/32”	1
768635	5 – 12 mm	size 3/64”	1
768635	10 – 75 mm	size 1/16”	1
768636	70 – 100 mm	size 5/64”	1
768662	90 – 150 mm	size 3/32”	1
768598	140 – 200 mm	size 7/94”	1
769041	190 – 300 mm	size 1/8”	1

PNME LONG PATTERN

9 spline inner, 88 mm long.

Fuel gas: Propane

Art. Nr.	Range	Size	Quantity
769494	3 – 6 mm	size 1/32”	1
769495	5 – 12 mm	size 3/64”	1
769496	10 – 75 mm	size 1/16”	1
769496	70 – 100 mm	size 5/64”	1
769498	90 – 150 mm	size 3/32”	1
769499	140 – 200 mm	size 7/94”	1
769501	190 – 300 mm	size 1/8”	1

ANME COOLEX NOZZLES

Art. Nr.	Range
768691	Cutting nozzle AGN 3-10 COOLEX
768692	Cutting nozzle AGN 10-25 COOLEX
768693	Cutting nozzle AGN 25-40 COOLEX
768694	Cutting nozzle AGN 40-60 COOLEX
768695	Cutting nozzle AGN 60-150 COOLEX

PNME COOLEX NOZZLES

Art. Nr.	Range
768652	Cutting nozzle PNME 3-10 COOLEX
768653	Cutting nozzle PNME 10-25 COOLEX
768696	Cutting nozzle PNME 25-40 COOLEX
768697	Cutting nozzle PNME 40-60 COOLEX
768654	Cutting nozzle PNME 60-150 COOLEX

AGNM GOUGING NOZZLES

94 mm long.
Fuel gas: Acetylene

Art. Nr.	Range	Size	Quantity
768698	6 – 8 mm Width × 3 – 9 mm Depth	size 13 – 1/32”	1
768661	8 – 11 mm Width × 6 – 11 mm Depth	size 19 – 3/64”	1
768699	9 – 12 mm Width × 9 – 12 mm Depth	size 25 – 1/16”	1

HA311 1 SHEET METAL NOZZLE

88 mm long.
Fuel gas: Acetylene

Art. Nr.	Range	Size	Quantity
768641	0 – 3 mm	0,3	1

ARCNM RIVET CUTTING NOZZLE

Fuel gas: Acetylene

Art. Nr.	Range	Size	Quantity
769230	50 mm	01/16/20	1

AFN TYPE ORBIT CUTTING NOZZLES

Fuel gas: Acetylene

Art. Nr.	Range	Size	Quantity
769416	0 – 3 mm	Sheet Metal ASFN	1
769285	3 – 6 mm	size 1/32”	1
769287	3 – 6 mm	size 3/64”	1
768825	20 – 30 mm	size 1/16”	1

Welding & Heating Nozzle

ORBIT SWAGED COPPER NOZZLES

For use on Orbit torch 1/4” × 26 TPI thread.
Fuel gas : Acetylene

Art. Nr.	Range	Size	Quantity
766232	0 to 1 mm	size 1	1
766233	1 – 1,5 mm	size 2	1
766234	1,5 – 2 mm	size 3	1
766235	1,5 – 2 mm	size 5	1
766236	2,5 – 3 mm	size 7	1
766237	3 – 4 mm	size 10	1
766238	4 – 5 mm	size 13	1
766239	5 – 6 mm	size 13	1
766240	6 – 8 mm	size 25	1

MK3 SWAGED COPPER TUBE NOZZLES

For use on Type 3/4/5 Welding torch 7/16” × 27 TPI Thread (Sizes 1-25 Type 2 & 3)
Fuel gas: Acetylene

Art. Nr.	Range	Size	Quantity
766244	0 to 1 mm	size 1	1
766245	1 – 1,5 mm	size 2	1
766246	1,5 – 2 mm	size 3	1
766247	1,5 – 2 mm	size 5	1
766248	2,5 – 3 mm	size 7	1
766249	3 – 4 mm	size 10	1
766250	4 – 5 mm	size 13	1
766251	5 – 6 mm	size 13	1
766252	6 – 8 mm	size 25	1

SUPERHEATING NOZZLES

For use on type 3/4/5 blowpipe in conjunction with heavy duty mixer 0766253 and necks 0766254 or 0766255. Can also be used with NM250 in conjunction with superheating adaptor 0766256. Fuel gas: Propane

Art. Nr.	Range	Size	Quantity
769472	1H	72 000 – 163 000 Btu/H	1
769473	2H	102 000 – 188 000 Btu/H	1
769473	3H	183 000 – 361 000 Btu/H	1
769475	4H	236 000 – 406 000 Btu/H	1
769476	5H	250 000 – 618 000 Btu/H	1
766256	Superheating adaptor for NM Cutters		1
